Distributed Cloud-Native Graph Database with NebulaGraph Docker Extension

Graph databases have become a popular solution for storing and querying complex relationships between data. As the amount of graph data grows and the need for high concurrency increases, a distributed graph database is essential to handle the scale.

Finding a distributed graph database that automatically shards the data, while allowing businesses to scale from small to trillion-edge-level without changing the underlying storage, architecture of the service, or application code, however, can be a challenge.

In this article, we’ll look at NebulaGraph, a modern, open source database to help organizations meet these challenges.

Banner nebulagraph extension

Meet NebulaGraph

NebulaGraph is a modern, open source, cloud-native graph database, designed to address the limitations of traditional graph databases, such as poor scalability, high latency, and low throughput. NebulaGraph is also highly scalable and flexible, with the ability to handle large-scale graph data ranging from small to trillion-edge-level.

NebulaGraph has built a thriving community of more than 1000 enterprise users since 2018, along with a rich ecosystem of tools and support. These benefits make it a cost-effective solution for organizations looking to build graph-based applications, as well as a great learning resource for developers and data scientists.

The NebulaGraph cloud-native database also offers Kubernetes Operators for easy deployment and management in cloud environments. This feature makes it a great choice for organizations looking to take advantage of the scalability and flexibility of cloud infrastructure.

Architecture of the NebulaGraph database

NebulaGraph consists of three services: the Graph Service, the Storage Service, and the Meta Service (Figure 1). The Graph Service, which consists of stateless processes (nebula-graphd), is responsible for graph queries. The Storage Service (nebula-storaged) is a distributed (Raft) storage layer that persistently stores the graph data. The Meta Service is responsible for managing user accounts, schema information, and Job management. With this design, NebulaGraph offers great scalability, high availability, cost-effectiveness, and extensibility.

Nebulagraph database architecture infographic
Figure 1: Overview of NebulaGraph services.

Why NebulaGraph?

NebulaGraph is ideal for graph database needs because of its architecture and design, which allow for high performance, scalability, and cost-effectiveness. The architecture follows a separation of storage and computing architecture, which provides the following benefits:

  • Automatic sharding: NebulaGraph automatically shards graph data, allowing businesses to scale from small to trillion-edge-level data volumes without having to change the underlying storage, architecture, or application code.
  • High performance: With its optimized architecture and design, NebulaGraph provides high performance for complex graph queries and traversal operations.
  • High availability: If part of the Graph Service fails, the data stored by the Storage Service remains intact.
  • Flexibility: NebulaGraph supports property graphs and provides a powerful query language, called Nebula Graph Query Language (nGQL), which supports complex graph queries and traversal operations.
  • Support for APIs: It provides a range of APIs and connectors that allow it to integrate with other tools and services in a distributed system.

Why run NebulaGraph as a Docker Extension?

In production environments, NebulaGraph can be deployed on Kubernetes or in the cloud, hiding the complexity of cluster management and maintenance from the user. However, for development, testing, and learning purposes, setting up a NebulaGraph cluster on a desktop or local environment can still be a challenging and costly process, especially for users who are not familiar with containers or command-line tools.

This is where the NebulaGraph Docker Extension comes in. It provides an elegant and easy-to-use solution for setting up a fully functional NebulaGraph cluster in just a few clicks, making it the perfect choice for developers, data scientists, and anyone looking to learn and experiment with NebulaGraph.

Getting started with NebulaGraph in Docker Desktop

Setting up

Prerequisites: Docker Desktop 4.10 or later.

Step 1: Enable Docker Extensions

You’ll need to enable Docker Extensions under the Settings tab in Docker Desktop. Within Docker Desktop, confirm that the Docker Extensions feature is enabled (Figure 2). Go to Settings > Extensions and select Enable Docker Extensions.

Docker desktop extensions settings
Figure 2: Enabling Docker Extensions within the Docker Desktop.

All Docker Extension resources are hidden by default, so, to ensure its visibility, go to Settings > Extensions and check the Show Docker Extensions system containers.

Step 2: Install the NebulaGraph Docker Extension

The NebulaGraph extension is available from the Extensions Marketplace in Docker Desktop and on Docker Hub. To get started, search for NebulaGraph in the Extensions Marketplace, then select Install (Figure 3).

Nebulagraph extensions marketplace
Figure 3: Installing NebulaGraph from the Extensions Marketplace.

This step will download and install the latest version of the NebulaGraph Docker Extension from Docker Hub. You can see the installation process by clicking Details (Figure 4).

Nebulagraph installation progress docker desktop
Figure 4: Installation progress.

Step 3: Waiting for the cluster to be up and running

After the extension is installed, for the first run, it normally takes fewer than 5 minutes for the cluster to be fully functional. While waiting, we can quickly go through the Home tab and Get Started tab to see details of NebulaGraph and NebulaGraph Studio, the WebGUI Utils.

We can also confirm whether it’s ready by observing the containers’ status from the Resources tab of the Extension as shown in Figure 5.

Nebulagraph resources docker desktop
Figure 5: Checking the status of containers.

Step 4: Get started with NebulaGraph

After the cluster is healthy, we can follow the Get Started steps to log in to the NebulaGraph Studio, then load the initial dataset, and query the graph (Figure 6).

Nebulagraph get started docker desktop
Figure 6: Logging in to NebulaGraph Studio.

Step 5: Learn more from the starter datasets

In a graph database, the focus is on the relationships between the data. With the starter datasets available in NebulaGraph Studio, you can get a better understanding of these relationships. All you need to do is click the Download button on each dataset card on the welcome page (Figure 7).

Nebulagraph starter datasets
Figure 7: Starter datasets.

For example, in the demo_sns (social network) dataset, you can use the following query to find new friend recommendations by identifying second-degree friends with the most mutual friends:

Nebula console demo sns
Figure 8: Query results shown in the Nebula console.

Instead of just displaying the query results, you can also return the entire pattern and easily gain insights. For example, in Figure 9, we can see LeBron James is on two mutual friend paths with Tim:

Nebula console demo sns results graph
Figure 9: Graphing the query results.

Another example can be found in the demo_fraud_detection (graph of loan) dataset, where you can perform a 10-degree check for risky applicants, as shown in the following query:

WHERE id(p)=="p_200" AND
p2.`applicant`.is_risky == "True"

The results shown in Figure 10 indicate that this applicant is suspected to be risky because of their connection to p_190.

Nebula console demo fraud detection graph
Figure 10: Results of query showing fraud detection risk.

By exploring the relationships between data points, we can gain deeper insights into our data and make more informed decisions. Whether you are interested in finding new friends, detecting fraudulent activity, or any other use case, the starter datasets provide a valuable starting point.

We encourage you to download the datasets, experiment with different queries, and see what new insights you can uncover, then share with us in the NebulaGraph community.

Try NebulaGraph for yourself

To learn more about NebulaGraph, visit our website, documentation site, star our GitHub repo, or join our community chat.
